MAGNETIC DRIVE AGITATORS - MDTA GMP
KWENG MAGNETIC DRIVE AGITATORS – MDTA GMP
- KWENG with its versatility in the arena of Magnetic Couplings and as a leading supplier of Magnetic Drive Pumps and Bottom Mixers, introduced the
Seal-less Magnetic Drive Agitators in early 2000. Continuing the objective of Zero emission, highest standards of safety, quality and reliability Kweng Magnetic Drive Agitators are prominent in the chemical, petrochemical, pharmaceutical, resins & food industries and has built a reputation
as an indigenous and innovative supplier of a first-class mixing equipment.
KEY FEATURE :
- Sterile Magnetic Drive Agitator design with special Hybrid & Ceramic Anti – friction bearings.
- Shaft Diameters from 40 mm to 130 mm
- Torque capacity > 5000 Nm.
- Pressure ratings up to 18 bar.
- Temperature rating up to 200ºC
- MOC – SS 316L, Hastelloy C etc.
Applications :
- Bio Technology
- Fermentation – Cell Culture
- Tissue Culture
- Bacterial
- Blending
- Food & Beverages
- Bio Reactor
- Fermentor
- Distillation
- Homogenizer
- Degassing
| Ceramic Ball Bearings | Standard | ZrO2/Si3N4/PEEK/PTFE |
|---|---|---|
| Optional | Hybrid SS/Si3N4 | |
| Agitator/ Impeller Shaft | Standard | AISI 316L (1.4435) |
| Optional | AISI 904L, Hastelloy C22 | |
| Fixation of Impeller | Standard | Modular – Sealed sliding Hub |
| Optional | Fixed – Welded to the shaft | |
| O-Rings | Standard | EPDM |
| Optional | FEP/Silicone/Viton | |
| Standards | Accordingly | ASME BPE |
| Surface Quality of Wetted parts | Standard | Ra: < 0.4 µm |
| Optional | Ra: < 0.25 µm | |
| Surface Treatment | Manual & e-polished | |
| Motor | Direct Drive/Geared Motor | |
| Max. Operating Temp. | 150°C | |
| Operating RPM | 10 – 350 | |
| Vessel Capacities | 20 L to 30,000 L | |
